Type-tagging strings in Rust

Author: Gavin Mendel-Gleason

Strings are pretty general data structures which can contain, depending on the language, nearly arbitrary byte sequences. While this generality makes them a very useful way of representing everything from blocks of text to binary data, it can also be a hassle when you want them to mean something in particular.

As such many languages have specific strings with encodings, or which are guaranteed to have a known length etc.

However, sometimes you need a kind of string which is very specific. In this case you need to vet a string to ensure that it meets some very specific criteria. Examples abound, including checking to see if a string is valid for insertion into a query to avoid SQL injection attacks for instance.

One technique which has been used for decades (I used this trick in SML in the early 2000s) is to tag your string with a type. Your vetting function is the only one which is allowed to introduce the type, and now you can safely ensure that everywhere the string is used, it is only the kind of string which is vetted, but including the vetting string type in the signature of the functions which use it.

The key idea: We leverage our type system to give us static guarantees about what we are talking about and uncover misuses of names.

The Problem: Three naming universes which must be distinct

In TerminusDB, we have a GraphQL endpoint which is auto-generated from your schema definition. This is a no-code method of creating endpoints which are extremely powerful and allow graph query.

However, GraphQL has a very narrow idea of what is an acceptable name. TerminusDB by comparison, allows names to be anything which can fit into a valid IRI. But most usage of these IRIs in TerminusDB is actually via a shorter "prefixed" form which is easier to work with than a full URL.

We have an automatic name conversion from our shorter form into GraphQL, but this "sanitization" process, required to make a valid GraphQL name, is necessarily lossy. Any attempt to create a non-lossy conversion will result in ugly large expressions in post cases.

Of course having a manual conversion defined should also be possible (although it is not yet implemented) but here again, we have to keep track of which universe we are in.

The problem then is that we need a triangle with interconversion everywhere:

        GraphQLName
      /            \
   ShortName — IriName

Ok, simple enough you say! Well it isn't rocket science to set up a number of different bimaps in rust that will give you this interconversion. Unfortunately though, it's very easy to just use the wrong name, in the wrong context leading to catastrophic failure!

If you use an IRI when you need a GraphQLName, GraphQL will explode on the unusual characters. If you try to use the GraphQLName where you need an IRI, the database will fail to find the object you're looking for. We need to keep the universes seperated, and hence we want to use the string vetting trick to tag a type on our string to ensure we keep the three universes completely segregated.

How this can work in Rust

We have one additional problem which is somewhat specific to rust (at least at first glance) and that's that we want to be able to tag our GraphQLName strings even if we haven't created ourselves. In rust this is a borrow. This additional complication is due to the fact that we are using Juniper, which represents GraphQL fields as a borrow of a string &str.

Here is how we decided to represent our string tagging structs:

#[derive(Clone, Debug, Eq, PartialEq, Ord, PartialOrd, Deserialize, Default, Hash)]
pub struct GraphQLName<'a>(pub Cow<'a, str>);
#[derive(Clone, Debug, Eq, PartialEq, Ord, PartialOrd, Deserialize, Default, Hash)]
pub struct IriName(pub String);
#[derive(Clone, Debug, Eq, PartialEq, Ord, PartialOrd, Deserialize, Default, Hash)]
#[repr(transparent)]
pub struct ShortName(pub String);

The first probably requires the most explanation. If we want to create a GraphQLName based on either a String or a &str we need some way to say we either have created a new thing, or are borrowing it from somewhere else. This is what a Cow does for us. It's implemented as follows:

pub enum Cow<'a, B: ?Sized + 'a>
where
    B: ToOwned,
{
    /// Borrowed data.
    Borrowed(&'a B),
    /// Owned data.
    Owned(<B as ToOwned>::Owned),
}

Basically it gives us two constructors, one for owned data and one for borrowed data. With a few convenience trait implementations we can kind of pretend this is string.

Some convenience implementation

The string versions are pretty straightforward, but to use the Cow approach effectively we need some helpers. One function which we implement as a member on GraphQLName is able to create a static version. The other just drops off the tagging of GraphQLName, which is important for interfaces which are external and do not know about GraphQLNames.

Of course, we always have to be careful about how we marshall in and out but our problem has been confined to what is essentially a perimeter security problem where we have to be very careful about how things getting injected into the type and then how the type is used. But this is much better than the original problem of semantic spaghetti.

impl<'a> GraphQLName<'a> {
    pub fn as_static(&self) -> GraphQLName<'static> {
        match &self.0 {
            Cow::Borrowed(s) => GraphQLName(Cow::Owned(s.to_string())),
            Cow::Owned(s) => GraphQLName(Cow::Owned(s.clone())),
        }
    }

    pub fn as_str(&self) -> &str {
        &self.0
    }
}

We also want to have a couple of simple implementations for our ShortName as this is the one which comes from TeriminusDB and from which we need to construct our.

impl ShortName {
    pub fn as_str(&self) -> &str {
        &self.0
    }

    pub fn sanitize(&self) -> GraphQLName<'static> {
        graphql_sanitize(&self.0)
    }
}

This implementation allows us not only to get the underlying str as a borrow, but we can sanitize a ShortName and get a GraphQLName. This is simply a renaming strategy defined with some regexp replace which produces a sensible name which is also within the viable GraphQL space of names (as defined by the regex: [_a-zA-Z][_a-zA-Z0-9]*).

Conversion between the various names is thereafter managed by functions which use BiMaps which remember how we sanitized our names. For instance, this fragment from ClassDefinition:

    pub graphql_to_iri: BiMap<GraphQLName<'static>, IriName>,
    pub graphql_to_short_name: BiMap<GraphQLName<'static>, ShortName>,

Now we can use a conversion function such as short_name_to_graphql_name to get the kind of thing we want to be talking about.

    pub fn short_name_to_graphql_name<'a>(&'a self, db_name: &ShortName) -> GraphQLName<'a> {
        self.short_to_graphql_name_opt(db_name)
            .unwrap_or_else(|| panic!("This class name {db_name} *should* exist"))
    }

When we need to drop back out of the definition at the boundary, we use the as_str member function. An example in the GraphQL code is below on line 18 where we need to drop back from the name (as GraphQLName) into a &str which is required by the Juniper interface.

    fn meta<'r>(
        info: &Self::TypeInfo,
        registry: &mut juniper::Registry<'r, DefaultScalarValue>,
    ) -> juniper::meta::MetaType<'r, DefaultScalarValue>
    where
        DefaultScalarValue: 'r,
    {
        let mut fields: Vec<_> = info
            .allframes
            .frames
            .iter()
            .filter_map(|(name, typedef)| {
                if let TypeDefinition::Class(c) = typedef {
                    let newinfo = TerminusTypeInfo {
                        class: name.as_static(),
                        allframes: info.allframes.clone(),
                    };
                    let field = registry.field::<Vec<TerminusType>>(name.as_str(), &newinfo);

                    Some(add_arguments(&newinfo, registry, field, c))
                } else {
                    None
                }
            })
            .collect();
...

There are a few places where we have to manually marshall a name in from Juniper, but in changing to our type-tagging we caught at least four naming bugs, which could work in some circumstances (in fact we had tests which covered cases that magically worked) but don't work in the general case.

It took about a full working day to convert the code, but given that we found real bugs, all in all it was a worthwhile experiment!
